AMD RYZEN™ 3 3100

SPECIFICATIONS:

• ‌No of CPU Cores: 4
• ‌No of Threads: 8
• ‌Base Clock: 3.6GHz
• ‌Max Boost Clock*: Up to 3.9 GHz
• ‌Total L1 Cache: 256KB
• ‌Total L2 Cache: 2MB
• ‌Total L3 Cache: 16MB
• ‌Unlocked*: Yes
• ‌CMOS: TSMC 7nm FinFET
• ‌Package: AM4
• ‌PCI Express® Version: PCIe 4.0
• ‌Thermal Solution (PIB): Wraith Stealth
• ‌Default TDP / TDP: 65W

SYSTEM MEMORY:

• ‌System Memory Specification: Up to 3200MHz
• ‌System Memory Type: DDR4

KEY FEATURES:

• ‌AMD Zen Core Architecture
• ‌AMD Ryzen™ Master Utility
• ‌AMD Ryzen™ VR-Ready Premium

FOUNDATION:

• ‌Product Family: AMD Ryzen™ Processors
• ‌Product Line: AmD Ryzen™ 3 Desktop Processors
• ‌Platform: Boxed Processor
• ‌OPN Tray: 100-000000284
• ‌OPN PIB: 100-100000284BOX
• ‌OPN MPK: 100-100000284MPK

EMX-A320-GAMING

SPECIFICATIONS:

• ‌AMD® 320 Chipset
• ‌Socket AM4 Processor
• ‌2x DDR4
• ‌Onboard Gigabit Ethernet Lan
• ‌Onboard 8 Channel HD Audio

1. ‌1 x PCIE x 16 Slot
2. ‌2 x PCIE x 1 Slot

INTERNAL CONNECTORS:

• POWER: 1 x 24-pin ATX power socket / 1 x 4-pin ATX 12V power outlet
• STORAGE: 4 x SATA III 6Gb/s connectors
• COOLING: 2 x fan connectors
• I/O: 1 x front panel header / 1 x front aufio header

‌2 x USB 3.0 connector for the four additional external USB / 2 x USB 2.0 connector for the four additional external USB 3.0 interface / 1 x COM connector

FORM FACTOR: Micro ATX; 226mmx185mm

REAR PANEL CONNECTORS:

‌1 x PS/2 keyboard interface / 1 x PS/2 mouse port

‌1 x Dsub / VGA interface / 1 x HDMI interface / 2 x USB 3.0 interface / 2 x USB 2.0 interface / 3 x Audio interface (Line In / Line Out / Mic In)

CATEGORIES: AMD AM4 SOCKET, MOTHERBOARDS
